AVerMedia CN312SW M.2 CaptureCard (2K SDI Dual / WideRange Temperature)

AVerMedia CN312SW M.2 CaptureCard (2K SDI Dual / WideRange Temperature)
  • Dual-Channel !
  • 2K SDI/HDMI !
  • M.2 !
  • Wide Range Temperature !

AVerMedia AVerGrabber CN312S, the 2K SDI Dual-Channel M.2 Video Capture Card, is equipped by two SDI channels with the embedded audio. With its SDI video source input, it is able to support an astounding uncompressed real-time video capture resolution of up to 2K (2048 x 1080).
At the frame rate of 60 fps, CN312S can improve the quality of a wide range of media recorded for businesses, universities, broadcasting, and manufacturing facilities, which can eventually provide a more lifelike and smooth video playback experience.
Wide Temperature and Conformal Coating Design AVerMedia delivers this advanced solution, which is capable of withstanding the extreme temperature envir
[more]

Share

509.00 EUR
incl. 19% VAT, plus shipping
In Stock (3 pcs)

Add to cart

AVerMedia AVerGrabber CN312S, the 2K SDI Dual-Channel M.2 Video Capture Card, is equipped by two SDI channels with the embedded audio. With its SDI video source input, it is able to support an astounding uncompressed real-time video capture resolution of up to 2K (2048 x 1080).
At the frame rate of 60 fps, CN312S can improve the quality of a wide range of media recorded for businesses, universities, broadcasting, and manufacturing facilities, which can eventually provide a more lifelike and smooth video playback experience.
Wide Temperature and Conformal Coating Design AVerMedia delivers this advanced solution, which is capable of withstanding the extreme temperature environment without compromising the video functionality. CN312SW (Wide Temperature Version) can offer the stable operation in the temperature range from -20°C to 70°C (-4°F to 158°F). Furthermore, CN312SC (Wide Temperature with Conformal Coating Version) thermally robust product is specifically designed to provide great reliability for the rugged and industrial applications to against moisture, dust, or chemicals.

  • Max. input resolution 2048 x 1080 60fps
  • Max. capturing/recording 1920 x 1080 60fps
  • Wide temperature and conformal coating design
  • CN312SW: Wide temperature version
  • CN312SC: Wide temperature with conformal coating version
  • The latest M.2 compact Gen2x4 interface
  • Hardware video processing:
    1. hardware scaling
    2. color space conversion




Host Interface Gen2 x 4
Audio Format SDI embedded audio
Audio Sampling Rate 48KHz
Connector Type BNC for SDI
Input Interface 2-channel 2K SDI
Video Format Driver support output: 4:2:0 8-bit : NV12, I420, YV12 4:2:2 8-bit : YUY2 4:4:4 8-bit: IYU2, BGR24, BGR32 SDK support output: 4:2:0 8-bit : YV12 4:2:2 8-bit : YUY2 4:4:4 8-bit: BGR24
Color Depth 8-bit (support 10-bit video input)
Channel No. 2 channels
Max. Input Resolution 2048 x 1080@60fps
Max. Recording Resolution 1920 x 1080@60fps (2-channel)
Encoding Mode Software Encoding
Multi-Card Support Yes
Supported OS Windows 7, 8.1, 10 (32/64-Bit) Linux (based on V4L2, support x64)
Form Factor M.2 (2280 Key M)
Dimension (W x L x H) 22 x 80 x 26.3 mm
Power Consumption 3.3 W
Operating Temperature CN312SW: -20°C ~ 70°C CN312SC: -20°C ~ 70°C (with 0.5m/s airflow)
Storage Temperature -40°C ~ 85°C
Operating Humidity 5% - 95% Relative Humidity
Safety Certification FCC / CE
Data sheet Download (PDF)
Data sheet Print view
Datasheet Download (PDF)
Manual Download
